Artnet /DMX Converter AD-2N
It's an Ethernet to DMX bidirectional converters.Provide two network Art-Net to DMX512 two way conversion capabilities.Equipment uses high-speed ARM processors,follow the standard Art-Net protocol,provide RJ45 network interfaces and standard DMX512 input/output interface.
ArtNet-DMX highly compatible protocol standards,practical,stable and reliable.
◆Connerctor
DMX:2x shielded&gold plated 3-pin XLR(female)
Network:1*10/100 Mbps RJ45 connector
Power supply:9-12V DC
◆DMX features
Support Agreement:DMX512,RDM(selected)ANSI E1.20
DMX port direction:input or outputconfigurable)
DMX port protection:built-in 1.5kv
DMX Port Match/Offset:yes
DMX Parameters:Frame Frequency:10-40fps/Break:176-352μs
◆Ethernet features
Support agreement:Art-Net,UDP,TCP,ICMP,DHCP
Port rate:10/100Base TX
Port datection:auto-negotiation,MDI/MDIX
◆Additional features
Configuration management software:search found,simple configuration
WEB configuration:support
◆Status report
LCD display configuration:setup information(ip address,subnet mask,DMX port settings)
Ethernet port indication:connection and activity
Run:LED indication
◆Weight:260g
◆Size: 11*9*5cm
