Light Source Configuration:

5*60W RGBW LEDs/48*2W Cool White (CW) LEDs/48*2W Warm White (WW) LEDs/48*0.5W RGB LEDs

Optical Performance:

Beam Angle: 2.8°–31°

Field Angle: 5°–46°

Dimming/Strobe:

0–100% smooth dimming/Multi-speed strobe effects

Mechanical Movement:

Tilt Movement: 202°

Control System:

Channel Modes: 17/27/55/58/88/90CH

Supported Protocols:DMX512/RDM/Art-Net/sACN

Firmware Upgrade: Via DMX connection

Physical Structure:

Display: Full-color OLED

Connectors: Signal: 5-pin XLR (3-pin optional)

Power: powerCON input/output

IP Rating: IP65

Key Features:

Linear zoom optical system

High-intensity beam with sharp edges

Advanced color mixing technology

Dimensions: 500 × 120 × 290mm (19.4" × 4.7" × 11.4")

Net Weight: 18kg (55lbs)
