power supply

Input voltage: 100~240V AC, 50/60Hz
Rated power: 1000W@220V

optics

Light source: 650W LED
Rated life: 20000 hours
Illumination: 5 meters distance 251000LX
Beam angle: 3°~40°
Color temperature: 8000K
Color rendering index: Ra: 70 in standard mode, Ra: 90 in high CRI mode

effect

Rotation angle: horizontal 540° vertical 270°; It has an automatic return function
Strobe: 0~25HZ
Color: 1 color wheel (8 colors white)
Pattern: 1 fixed gobo (6 patterns flowing water effect white light),
7 rotating patterns, each glass pattern can be independently forward and reverse
Prism: 4 prisms and 8 prisms, superimposed prisms, each prism can be rotated forward and backward independently
Dimming: 0-100% linear adjustment
Atomization: Independent atomization
Focus: DMX linear adjustment
Cutting: 1 set of four-sided cutting system, 90° rotation

control

Control mode: DMX512, RDM, master-slave synchronous control mode, self-propelled mode, single scene mode
Channel: 33CH
Physical characteristics
Degree of protection: IP20
Housing: High temperature resistant flame retardant plastic
Power Connection: powerCON power input/output
Signal connection: 3-core &5-core DMX signal input/output
Product net weight: 25kg
Working environment: -20°C~40°C
Luminaire size: 383x274x668mm
Package size: 750x360x470mm

Standard configuration: power cord 1PCS, fuse rope 1PCS, DMX signal cable 1PCS, integrated folding light hook 1PCS
